TH-110 High-Accuracy
Haze & Transmittance Meter
The TH-110 is a high-accuracy benchtop haze and transmittance meter designed for precise measurement of transparent and translucent materials including films, plastics, glass, packaging and display materials.
It supports both ASTM and ISO haze measurement methods, with a 0–100% measurement range and 0.01 resolution for haze and transmittance. With excellent repeatability, multiple measurement apertures and a large 7-inch touchscreen, the TH-110 is well suited to laboratory, quality-control and production environments.
Features
High-Accuracy Measurement
Precise haze and transmittance measurement with excellent repeatability.
Reduced Ambient-Light Influence
Signal-processing technology helps minimise the effect of surrounding light on measurement results.
Flexible Sample Measurement
Open measurement area with horizontal or vertical operation for larger or differently shaped samples.
Product Overview
The TH-110 is designed for accurate haze and transmittance measurement where repeatability, flexibility and ease of sample handling are important. Its open measurement area allows both small and large samples to be positioned easily, with the instrument supporting horizontal or vertical measurement depending on the material being tested.
Multiple illuminants, including A, C and D65, provide flexibility for different measurement requirements, while the 21 mm and 7 mm apertures accommodate a range of sample sizes. Signal-processing technology helps reduce the influence of surrounding light, supporting more reliable results in normal laboratory and production environments.
The large 7-inch touchscreen provides clear measurement results and straightforward operation, while haze and total transmittance can be measured across a 0–100% range with 0.01 resolution.
A, C & D65 Illuminants
Flexible light-source options for different measurement needs.
21 mm & 7 mm Apertures
Suitable for a range of sample sizes and applications.
0–100% Range
Measures haze and transmittance across a full
0–100% range.
0.01 Resolution
Fine resolution for haze and transmittance results.
7-Inch Touchscreen
Large touchscreen display for clear results and simple operation.
The Film Fixture for Flexible Film Measurements
The Film Fixture for Flexible Film Measurements
TH-110 Technical Specifications
Detailed Specifications for the TH-110 Haze & Transmittance Meter
Measurement
Measurement Geometry: 0/d
Measurement Parameters: Haze and Total Transmittance
Measurement Range: 0–100%
Haze Resolution: 0.01
Transmittance Resolution: 0.01
Haze Repeatability: ≤0.05
Transmittance Repeatability: ≤0.1
Optics & Illumination
Measurement Apertures: 21 mm and 7 mm
Illuminants: CIE-A, CIE-C and CIE-D65
Light Source: LED
Spectral Response: CIE luminosity function Y/V(λ)
Integrating Sphere Diameter: 154 mm
Instrument
Display: 7-inch touchscreen
Interface: USB
Storage: Mass data storage
Power Supply: DC 12 V
Physical & Environmental
Sample Capacity: Open measurement area; sample thickness up to 145 mm
Operating Temperature: 5–40°C
Storage Temperature: -20–45°C
Instrument Size: 310 × 215 × 540 mm
Weight: Approx. 6 kg
Measurement Standards
ASTM: ASTM D1003
ISO: ISO 13468, ISO 14782
JIS: JIS K 7361, JIS K 7136
Optional Accessories
-
Haze calibration standards
-
Custom aperture sizes
-
Soft film measurement fixture
-
Liquid / sheet material fixture
